Medium Voltage Electrical Towers Drawings Details; Medium voltage towers used in electricity transmission and distribution. Drawing details of the medium-voltage mast is made in AutoCAD . Sep 22, 2015rare
3D Breadboards Model Solidworks . What is the breadboard ? A breadboard is a construction base for prototyping of electronics. Originally it was literally a bread board, a polished piece of wood used for slicing bread. In the 1970s the solderless breadboard (AKA plugboard, a terminal array board) became available and nowadays the term “breadboard” […]
Led Diode 3D Solidworks Drawing What isthe Led Diode ? A light-emitting diode (LED) is a two-lead semiconductor light source. It is a p–n junction diode, which emits light when activated.When a suitable voltage is applied to the leads, electrons are able to recombine with electron holes within the device, releasing energy in the form […]
Caliper (compass) 3D SolidWorks Drawings What is the Caliper ? A caliper (British spelling also calliper, or in plurale tantum sense a pair of calipers) is a device used to measure the distance between two opposite sides of an object. A caliper can be as simple as a compass with inward or outward-facing points. The tips […]
Two Position Microswitch 3D Solidworks Drawings . What is the microswitch ? A miniature snap-action switch, also trademarked and frequently known as a micro switch, is an electric switch that is actuated by very little physical force, through the use of a tipping-point mechanism, sometimes called an “over-center” mechanism. Sep 21, 2015rare
Steam Engine 3D Solidworks Drawings A steam engine is a heat engine that performs mechanical work using steam as its working fluid. Sep 21, 2015rare
Electrical Motor Stator 3D Inventor Drawing. What is the stator ? Depending on the configuration of a spinning electromotive device the stator may act as the field magnet, interacting with the armature to create motion, or it may act as the armature, receiving its influence from moving field coils on the rotor. The first DC generators […]
Pneumatic Cylinder 3D Solidworks. Pneumatic cylinder(s) (sometimes known as air cylinders) are mechanical devices which use the power of compressed gas to produce a force in a reciprocating linear motion. You can download the file in the detailed drawings which were made as part of SolidWorks 3D pneumatic cylinders . Sep 21, 2015rare
Flow control valve regulates the flow or pressure of a fluid. Control valves normally respond to signals generated by independent devices such as flow meters or temperature gauges. Sep 20, 2015rare
1N4007 Diode İnventor 3D Drawings. The 1N4001 series (or 1N4000 series) is a family of popular 1.0 A (ampere) general purpose silicon rectifier diodes commonly used in AC adapters for common household appliances. Blocking voltage varies from 50 to 1000 volts. This diode is made in an axial-lead DO-41 plastic package. Sep 20, 2015rare
Electrical Motor Parts – Rotor 3D Inventor Drawings.The rotor is a moving component of an electromagnetic system in the electric motor, electric generator, or alternator. Its rotation is due to the interaction between the windings and magnetic fields which produces a torque around the rotor’s axis. Sep 20, 2015rare
15 Pin VGA Connector Invertor 3d Drawings. A Video Graphics Array (VGA) connector is a three-row 15-pin DE-15 connector. The 15-pin VGA connector is found on many video cards, computer monitors, and high definition television sets. On laptop computers or other small devices, a mini-VGA port is sometimes used in place of the full-sized VGA connector. […]
